$1.50
Description
The Raspberry Pi Pico Headers Kit provides you with the exact set of solderable headers to get your Raspberry Pi Pico connected to a breadboard or other circuit. This set includes two 20-pin headers, and one 3-pin header; the pins are spaced by 0.1". Note: Soldering is required for functionality and physical attachment to the board. Additionally, a Raspberry Pi Pico is NOT included with these headers and will need to be purchased separately.Includes
- 1x Male PTH Header 3-pin
- 2x Male PTH Header 20-pin
Features
- ATSAMD21G18 32-bit/48MHz ARM Cortex-M0+
- 4MB Flash Memory
- 32KB SRAM
- 32KB of EEPROM (emulated in Flash)
- 26 GPIO Count
- 14 ADC Channels at 12-bit Resolution
- Analog-to-Digital and Digital-to-Analog Converters (ADC & DAC)
- Vin: 4.2V-6.0V for charger – otherwise 3.5V-6.0V
- VBATT: 3.7V Lipo
- VCC: 600mA @3.3V
- Arduino R3 Layout
- Integrated USB Controller
- RGB LED
- UF2 Bootloader
- Qwiic Connector
Documents
- Schematic
- Eagle Files
- Hookup Guide
- Datasheet (10MB PDF)
- Graphical Datasheet
- SAMD Arduino Core
- GitHub
- Compare SparkFun RedBoards
